Disc centrifuge which have higher rotation speeds, are being used to separate the mixtures of liquid-liquid and liquid-solid substances having different densities. The liquid or solid particles having the highest density are accumulated on the outer circumference of the separator drum, due to the high centrifuge force in the separators, while the other one having lower density remains in the center. Thereafter, both of those two phase or particles are discharged from different outlets.
Feature:
• Full automation possible with PLC automatic control panel.
• Centrifugal separation requiring no filter media.
• High reliability drive train system backed by delivery of over 1,000 units a year.
• Bowl design with superior separation performance and with good response to discharge loads.
• Pilot valve regulates total/partial discharge of solids.
• Super partial discharger (option) minimizes liquid loss and maximizes thickening of solid
• fraction for discharge.
• Vibration-proof design realizes long working life.
• Full automation possible with PLC automatic control panel
Application Scope:
• Beverage: Wine, tea, coffee and beer.
• Juices: Vegetable juices, various kinds of fruit juices
• Vegetable oil: Coconut oil, colza oil, cotton seed oil, corn oil, palm oil, soybean oil, peanut oil, rice oil, sesame oil, safflower oil,
• Animal oil: Fish oil and other animal oil.
• Mineral oil: Fuel oil, diesel oil, lubrication oil, transformer oil and waste oils.
Technical parameters :
|
Model
|
Bowl Speed(rpm)
|
Capacity (Per Hour)
|
Running Load(Watts)
|
Width
|
Front to Back
|
Height
|
|
250
|
7300
|
500
|
4
|
850
|
850
|
1200
|
|
400
|
7038
|
1500
|
7.5
|
1500
|
1100
|
1550
|
|
500
|
6600
|
5000
|
15.5
|
1772
|
1500
|
1855
|
|
550
|
6200
|
8000
|
18.5
|
1970
|
1560
|
1970
|
•24 months long guarantee period from machine arriving date.
•Abundant spare parts in stock are available to provide.
•Your suggestions or any comments & reflection would be treated in priority.
•Your workers can get training easily by net video.
