Steam shrink tunnel+steam generator
Supplier: FUYI Machinery
Share to:
Details
Steam shink tunnel packing machine with automatic electric heating steam generator
Application:
This machine is mainly for the label shrinkage of bottle-shaped, can-shaped, barrel-shaped and cup-shaped
products, and can shrink the bottle mouth, bottle body, bottle bottom and the whole. It is suitable for the label shrinkage of glass bottles, plastic bottles, paper cups and other containers in the food, medicine, cosmetics, pesticide and other industries.
Characteristic:
*Different and irregular bottles are all suitable.
* More cost-effective. The shrinkage effect is good;
* The whole machine shell is made of 304 stainless steel.
*It complies with international safety standards.
Technical parameters :
|
Model: |
FY-1520 Steam shrink machine
|
Model: |
KN-24W steam generator |
|
Voltage: |
380V 50Hz 3 P |
Power supply: |
380V/50hz 3 P |
|
Power: |
120W |
Power: |
24KW |
|
Load capacity: |
25kg |
Steam saturation temperature : |
170℃ |
|
Conveying speed: |
0-12m/min (adjustable) |
Evaporation capacity: |
32kg / h |
|
Tunnel entrance size: |
L1500 * W200 * H200mm（can customized to be higher) |
Steam pressure:
|
0.4-0.7Mpa |
|
Material: |
Stainless steel 304 |
Material: |
Stainless steel 304 |
|
Overall size: |
L2500 * W460 * H1800mm |
Overall size: |
L700*W460*H1050mm |
|
Machine weight: |
400kg |
Machine weight: |
78kg |
