ZPW-23D High Speed Rotary tablet Press Machine for Bicolor Tablets
Supplier: FUYI Machinery
Share to:
Details
ZPW-23D High Speed Rotary tablet Press Machine for Bicolor Tablets
Brief introduction：
This machine is a kind of automatic rotating and continuous pressing machine. It is mainly used in pharmaceutical industry, food industry, chemical industry, electronics industry and so on. Granular raw materials are pressed into tablets. This machine can not only press circular sheets of various specifications, but also special-shaped sheets, double-layer sheets, double-sided lettering sheets and circular sheets of various shapes.
Technical Parameters：
|
Model |
ZPW23D(Φ320) |
ZPW23D(Φ420) |
|
Quantity of punch&die(Set) |
23 |
23 |
|
Max. Pressure (kn) |
100 |
100 |
|
Max. Dia. of Tablet (mm) |
29 |
32 |
|
Max. thickness of tablet (mm) |
12 |
12 |
|
Max. depth of Filling (mm) |
20 |
25 |
|
Rotate speed (r/min) |
10-30 |
20 |
|
Production Capacity (pcs/h) |
82800 |
17600-55200 |
|
Power(kw) |
4 |
4 |
|
Voltage(V/Hz) |
380/50 |
380/50 |
|
Net weight (kg) |
2000 |
2300 |
|
Dimension(mm) |
1300*1100*1900 |
600*960*1750 |
Samples:
